- Description and Features
The machine is very different from ordinary folders because it clamps the work piece with a powerful electro-magnet rather than by mechanical means. This leads to numerous advantages as following. It gives you much more freedom to make the shapes you want.
a) Much greater versatility than conventional sheet metal benders.
b) No limitation to depth of boxes.
c) Can form deep channels, and completely closed sections.
d) Automatic clamping and unclamping means faster operation, less fatigue.
e) Accurate and continuous indication of beam angle.
f) Quick and accurate setting of angle stop.
g) Unlimited throat depth.
h) Infinite length bending in stages is possible.
i) Open ended design allows folding of complex shapes.
j) Machines can be ganged end-to-end for long bending.
k) Adapts easily to customised tooling (clamp bars of special cross-sections).
l) Self-protecting - machine cannot be overloaded.
m) Neat, compact and modern design.
Optional Accessories:
Narrow Clamping Bar, Slotted Clamping Bar and Foot switch.
| Model | EB625 | EB1000 | EB1250 | EB2000 | EB2500 | EB3200 |
| Max capacity | 625*1.6mm | 1000*1.6mm | 1250*1.6mm | 2000*1.6mm | 2500*1.6mm | 3200*1.6mm |
| (length*thickness) | 2’*16ga | 3’*16ga | 4’*16ga | 6’*16ga | 8’*16ga | 10’*18ga |
| Clamping force | 3ton | 4.5ton | 6ton | 9ton | 12ton | 10ton |
| Duty cycle | 30% | |||||
| Back gauge | 390mm | 640mm | ||||
| Foot switch | NO | Standard | ||||
| Nominal current | 4Amp | 6Amp | 12Amp | 15Amp | ||
| Protection | Thermal cut-out 70℃ | |||||
| Bending-edge length | 670mm | 1050mm | 1300mm | 2090mm | 2590mm | 3290mm |
| Distance between lifters | 630mm | 1010mm | 1260mm | 2028mm | 2528mm | 3228mm |
| Packing size | 83*112*38cm | 120*112*38cm | 145*112*38cm | 220*112*38cm | 270*112*38cm | 340*112*38cm |
| N.W./G.W. | 102/107kg | 142/177kg | 175/220kg | 290/360kg | 330/420kg | 400/510kg |
