| Parameters | Unit | Q11D-3*1300 | Q11D-3*1500 | Q11D-3*1600 | Q11D-2.5*2000 |
| The maximum shear plate thickness | mm | 3 | 3 | 3 | 2.5 |
| The maximum shear plate width | mm | 1300 | 1500 | 1600 | 2000 |
| The ultimate strength of shearing plate | N/mm² | ≤450 | ≤450 | ≤450 | ≤450 |
| Shear angle | ° | 2°10′ | 2° | 2° | 1°50′ |
| After the expected maximum distance | mm | 350 | 350 | 350 | 350 |
| The number of strokes | rpm | 30 | 30 | 30 | 30 |
| Main motor power | kw | 4.5 | 4.5 | 4.5 | 4.5 |
| Over dimensions | mm | 1860*1200*1200 | 2060*1200*1200 | 2200*1360*1260 | 2600*1360*1320 |
| Machine weight | kg | 1200 | 1300 | 1400 | 1800 |
